KVIT Lyuta 60

Detailed Description

KVIT Lyuta 60 is a powerful 18-60 kW pellet burner for heating large homes and commercial facilities. Ceramic automatic ignition eliminates open flame and manual firing, while self-cleaning cascade grates reduce ash-pan servicing. The grates and combustion chamber body are made of 5 mm AISI 310s heat-resistant steel for a long service life under high loads. Two-level fire protection improves operating safety. The burner runs on wood pellets and agro-pellets, giving flexibility in fuel choice and lowering operating costs.

Burner Application

Suitable for large private homes and commercial facilities up to 600 m² — shops, car services, greenhouses, warehouses and small production sites that need reliable autonomous heating with enhanced fire safety. Designed for intensive use throughout the entire heating season.

Delivery Set

• ✓
  KVIT Lyuta 60 burner, assembled
• ✓
  PLUM ecoTOUCH 360 controller
• ✓
  Ceramic ignition element
• ✓
  Pellet feed auger
• ✓
  Mounting kit for installation on the boiler
• ✓
  Installation and operation manual

Key Advantages of the Model

• ✓
  Ceramic ignition without open flame
• ✓
  Self-cleaning cascade grates reduce maintenance
• ✓
  Reinforced heat-resistant AISI 310s steel (5 mm) for high loads
• ✓
  Two-level fire protection
• ✓
  Runs on wood pellets and agro-pellets

How Pellet Burners Work

A pellet burner operates on the principle of automatic fuel feeding: pellets are carried from the hopper by an auger conveyor into the combustion chamber, where a ceramic element ignites them without an open flame or manual lighting. A fan forces in air to ensure complete combustion and high efficiency, while ash falls through self-cleaning cascade grates, reducing the need for maintenance. An electronic controller regulates the fuel and air feed based on the set temperature, maintaining stable, economical operation in a fully automatic mode.
