KVIT Lyuta 27

Detailed Description

KVIT Lyuta 27 is an 8-27 kW pellet burner for efficient heating of private homes and small industrial and utility premises. Ceramic automatic ignition eliminates open flame and manual firing, while self-cleaning cascade grates reduce ash-pan servicing. The combustion chamber body is made of 3 mm AISI 310s heat-resistant steel for a long service life even under intensive use. The burner runs on wood pellets and agro-pellets, giving flexibility in fuel choice and lowering operating costs.

Burner Application

Suitable for private houses up to 270 m², as well as garages, workshops and small commercial premises that need autonomous, economical heating without constant human supervision. A good choice for owners switching from wood or coal to a cleaner, automated solution with power to spare.

Delivery Set

• ✓
  KVIT Lyuta 27 burner, assembled
• ✓
  PLUM ecoTOUCH 360 controller
• ✓
  Ceramic ignition element
• ✓
  Pellet feed auger
• ✓
  Mounting kit for installation on the boiler
• ✓
  Installation and operation manual

Key Advantages of the Model

• ✓
  Ceramic ignition without open flame
• ✓
  Self-cleaning cascade grates reduce maintenance
• ✓
  Heat-resistant AISI 310s steel (3 mm) for a long service life
• ✓
  Runs on wood pellets and agro-pellets
• ✓
  Power reserve up to 27 kW for larger homes

How Pellet Burners Work

A pellet burner operates on the principle of automatic fuel feeding: pellets are carried from the hopper by an auger conveyor into the combustion chamber, where a ceramic element ignites them without an open flame or manual lighting. A fan forces in air to ensure complete combustion and high efficiency, while ash falls through self-cleaning cascade grates, reducing the need for maintenance. An electronic controller regulates the fuel and air feed based on the set temperature, maintaining stable, economical operation in a fully automatic mode.
